Programming the EVOONE442 Fortin EVO-ONE remote car starter involves several steps. The exact process may vary depending on your vehicle and the specific Fortin EVO-ONE model you are using, but the general procedure is as follows:
Preparation-
Ensure the EVO-ONE Module is Installed: Make sure the Fortin EVO-ONE module is properly installed in your vehicle. This typically involves connecting the module to your vehicle's ignition system, CAN bus, and other relevant systems.
-
Gather Tools: You may need a programming cable (such as the Fortin Flash Link Updater) and a computer with internet access.
-
Access the Programming Mode: To program the remote, you will need to access the EVO-ONE's programming mode, which is usually done through the module's control button.
-
Enter Programming Mode:
- Turn the vehicle's ignition to the ON position (do not start the engine).
- Press and hold the programming button on the EVO-ONE module until the LED lights turn on, then release the button.
-
Programming the EVO-ONE:
- Programming with a Fortin Flash Link Updater:
- Connect the Flash Link Updater to your computer via USB.
- Open the Fortin Flash Link Manager software.
- Connect the EVO-ONE module to the Flash Link Updater.
- Follow the on-screen instructions to select your vehicle make, model, and year.
- Flash the module with the appropriate firmware for your vehicle.
- Once the firmware is flashed, disconnect the Flash Link Updater.
- Manual Programming (if not using Flash Link Updater):
- Press the module’s programming button while in programming mode.
- The LED lights on the module will indicate different options. Refer to the manual to select the appropriate option for your vehicle (e.g., door lock configuration, remote start, etc.).
- Use the vehicle’s key or remote to lock and unlock the doors as part of the programming process. This step helps synchronize the remote with the vehicle’s system.
- Programming with a Fortin Flash Link Updater:
-
Pairing the Remote:
- After flashing or manual programming, you may need to pair the remote with the EVO-ONE module:
- Turn the ignition off and then back on.
- Within 10 seconds, press and hold the lock button on the remote for 5 seconds.
- The parking lights should flash to indicate successful pairing.
- After flashing or manual programming, you may need to pair the remote with the EVO-ONE module:
-
Test the System:
- Test all functions of the remote, including lock, unlock, remote start, and trunk release (if applicable).
- If any functions do not work, double-check the programming steps and consult the manual.
-
Exiting Programming Mode:
- Once programming is complete, turn off the vehicle’s ignition.
- The module will exit programming mode automatically.
- Firmware Updates: If the system does not work as expected, check for any available firmware updates for your EVO-ONE module using the Flash Link Updater.
- Module Reset: If necessary, you can reset the module by following the reset procedure in the manual, then start the programming process again.
- Reassemble any vehicle components that were removed for installation or programming.
- Ensure the module and remote are functioning correctly before considering the installation complete.
If these instructions don't match your exact setup or you encounter any issues, consult the Fortin EVO-ONE manual specific to your vehicle or seek professional installation assistance.
